LED LINEARLIGHT HG-L205-24W/2ft -19-20

B站不支持收货地址

B站不支持库存规格

MOQ: 100PCS

Place of Origin: China

Delivery Time: 30-35 Working days

Start Port: Zhong Shan Port

Certification: UL /CUL, ETL /CETL, SAA, CE

B站不支持优惠卷

Inquire Online
Download

Cancel

Add success, do you want to check your shopping cart?

Ok Close

B站不支持产品保障

Product discription

◕ Osram, Philips, Tridonic or meanwell LED driver for 120V-277V/60Hz, 347V/60Hz, 240V/50Hz

◕ Ideal or WAGO UL/CUL approved quick disconnector VDE approved terminal block

◕ Everlight or Samsung LED Chips

Applications

Electrical Component

◕ Osram, Philips, Tridonic or meanwell LED driver for 120V-277V/60Hz, 347V/60Hz, 240V/50Hz

◕ Ideal or WAGO UL/CUL approved quick disconnector VDE approved terminal block

◕ Everlight or Samsung LED Chips

Specification

◕ Die formed of 0.5mm cold-rolled steel body
◕ All steel surface are painted after fabrication with high gloss backed white coated powder
◕ High reflectance backed white acrylic paint finished
◕ High-diffusion light-milky PC diffuser

OPTION

◕ Available for installing with dimmable & emergency kits
◕ Available for installing with sensor
◕ Available for hanging

Application

◕ Shop / School

◕ Office / Hotel

◕ Conference Room / Hospital

Technical Data

MODEL	WATTS	LUMEN	LED TYPE	LAMP SIZE(L X W X H )	PACKAGE SIZE	PCS/CTN
HG-L205-24W/2ft	24W/2ft	3120 LM	SMD 2835	616x82.5x93.5mm	655x205x225mm	4
HG-L205-36W/2ft	36W/4ft	4680 LM	SMD 2835	1206x82.5x93.5mm	1245x205x225mm	4
HG-L205-42W/2ft	42W/8ft	5460 LM	SMD 2835	2438x82.5x93.5mm	2480x205x225mm	4
HG-L205-68W/2ft	68W/8ft	8840 LM	SMD 2835	2438x82.5x93.5mm	2480x205x225mm	4

MODEL	WATTS	LUMEN	LED TYPE	LAMP SIZE(L X W X H )	PACKAGE SIZE	PCS/CTN
HG-L205B-252F	15/20/25W/2ft	3250LM	SMD 2835	605x60x82mm	635x290x150mm	6
HG-L205B-404F	20/25/40W/4ft	5200 LM	SMD 2835	1175x60x82mm	1205x290x150mm	6
HG-L205B-658F	55/60/65W/8ft	8450 LM	SMD 2835	2327x60x82mm	2355x290x150mm	6
